US-60V12 (12V 60W)

In stock

Menge Preis
1 - 4 13,49
5 - 9 13,19
10 - 19 12,79
20 + 12,39

Price on request for order quantity from 50 pieces

Price plus VAT, plus shipping cost

Delivery time: 2-5 workdays inside EU

In stock

Description

LED Trafo 12V 60W constant voltage for LED Strip Lamp super slim Furniture installation LED Driver Treiber Transformator

US-60V12

LED power supply for 12 Vdc constant voltage
5 A (60 W) max., IP20, independent installation, non-dimmable
Flicker free according to IEEE 1789

Electrical Data

Input voltage (nominal) 220…240 Vac
Input voltage (range) 198…264 Vac
Mains Frequency 50/60 Hz
Power Factor (λ) >0.95   220…240 Vac
Input Current 0.46 A max.   Full Load, 195 Vac
No-load loss ≤0.5 W
Inrush Current 50 A max.
Leakage Current < 0,7 mA   240 Vac
Output Voltage 12 Vdc
Output Current 0…5 A
Output Power (nominal) 60 W max.
Efficiency ≥ 87 %
Life Time > 50,000 h    40 °C
Dimmable No



Operating Condition

LED Trafo 12V 60W constant voltage for LED Strip Lamp super slim Furniture installation LED Driver Treiber Transformator

Operating Ambient Temperature (ta) -20…+45 °C
Max. Surface Temperature (tc) 90 °C
Protection Class II
Type of Protection IP20



Protection

Short Circuit Protection Yes *
Overload Protection Yes *   105…150 %
Overheating protection Yes *


(*) The output shuts off and will be resumed, after problem is removed and led driver is restarted.



Standards & Certificates

Standards (LVD) EN 61347-1, EN 61347-2-13
EN 62493
Standards (EMC) EN 61000-3-2, EN 61000-3-3
EN 61000-4-2, EN 61000-4-5
EN 55015, EN 61547
Approval Marks CE
RoHS Compliant Yes



Installation

LED Trafo 12V 60W constant voltage for LED Strip Lamp super slim Furniture installation LED Driver Treiber Transformator

Type of Installation Independent installation
Type of Connection Screw terminal
Cable Cross-section, input side 0.75…1.5 mm²
Cable Cross-section, output side 0.75…1.5 mm²
Cable Preparation length, input side 6…8 mm
Cable Preparation length, output side 6…8 mm



Dimension



Connection



LED power supply US-60-12 LI: LED transformer constant voltage, input 220 – 240 V (AC), output 12 V (DC), non-dimmable, independent installation.
Power: Ideal for LEDs (strips, lamps, GU5,3 / MR16, G4 / MR11) up to 60 W, parallel connection possible. Our products can be used with full load.
Assembly: dimensions 305 x 30 x 17 mm (L x W x H), ambient temperature (ta) -10 – +45 °C. Connection by screw clamps, suitable for furniture installation.
Safety: Protection class IP20, protection device equipped with overload protection, short circuit protection, overvoltage protection and overheating protection.
Quality: CE, TÜV, MM approval; Service life > 30.000 hours; Surface temperature (tc) 90°C.
huatec led transformer power supply driver transformator 12v 12 volt dc constant voltage same voltage super slim 60w 60 watt led strip lamp gu5.3 mr16 g4 mr11
LED transformer 12V 60W constant voltage slim.

For business customer, who wants to order our porducts in large quantities or learn more about our new products, please contact us and download our product catalog.
