CS5-18C350 (350mA 18W)


In stock

(0 customer reviews)
1 - 48,61
5 - 98,39
10 - 198,19
20 +7,99


Price on request for order quantity from 50 pieces

Price plus VAT, plus shipping cost

Delivery time: 2-5 workdays inside EU

In stock



LED power supply for 350 mA constant current
31…52 Vdc, 10.9…18.2 W, IP65, built-in installation, non-dimmable

Electrical Data

Input Voltage (nominal)100…240 Vac
Input Voltage (range)90…264 Vac
Mains Frequency50/60 Hz
Power Factor (λ)0.94C    Full Load, 100…240 Vac
Input Current0.28 A max.    Full Load, 90 Vac
Inrush Current30 A max.
Leakage Current< 0.7 mA    240 Vac
Output Voltage31…52 Vdc
Output Current350 mA
Output Power (nominal)10.9…18.2 W
Efficiency≥ 86 %
Life Time> 50,000 h    50 °C, 240 Vac


Operating Condition

Operating Ambient Temperature (ta)-20…+50 °C
Max. Surface Temperature (tc)80 °C
Permitted rel. Humidity20…90 %
Protection ClassII
Type of ProtectionIP65



Short Circuit ProtectionYes *
Overload ProtectionYes *   105…120 %
Overvoltage ProtectionYes *    > 62 Vdc

(*) The output shuts off and will be resumed, after problem is removed and led driver is restarted.


Standards & Certificates

NormenEN 61347-1, EN 61347-2-13
EN 61000-3-2, EN 61000-3-3
EN 55015, EN 61547
Approval MarksCE, UKCA
RoHS CompliantYes



Cable Length, input side100(±5) mm
Cable Length, output side130(±5) mm
Cable Cross-Section, input side2x 20AWG
Cable Cross-Section, output side2x 20AWG
Cable Preparation Length, input side3 mm tinned
Cable Preparation Length, output side3 mm tinned
