LED Driver Slim TRIAC Dimmable 24V 100W 4.16A, IP20

LED Driver Slim TRIAC Dimmable 24V 100W 4.16A, IP20

Modell: US-100V24-D4

  • Dimmable: Smooth, flicker-free dimming via leading-edge and trailing-edge phase-cut

  • Ultra-slim: Compact dimensions of just 304x30x19 mm, ideal for hidden installations

  • Safety: Short-circuit, overload, overvoltage and overheating protection. Suitable for furniture installation

  • Comfort: Flicker-free according to IEEE 1789, helping reduce eye strain and improving video recording quality

€29,99 / pc excl. VAT
€35,69 / pc incl. 19% VAT
From Net/pc Gross/pc
1 €29,99 €35,69
5 €29,49 €35,09
10 €28,99 €34,50
20 €28,49 €33,90
◉ In stock
Specifications
Input Voltage
220...240 Vac
Input Current
0,6 A max.
Output Voltage
24 Vdc
Output Current
0,83...4,16 A
Output Power
20...100 W
Dimming method
TRIAC
IP Rating
IP20
Dimensions
Dimension Graph for LED Driver Slim TRIAC Dimmable 24V 100W 4.16A, IP20
