LED Driver TRIAC Dimmable 48V 100W 2.08A, IP20

LED Driver TRIAC Dimmable 48V 100W 2.08A, IP20

Modell: LS-100V48-D3

  • Dimmable: Smooth, flicker-free dimming via leading-edge and trailing-edge phase-cut

  • Extended: 48V output for extended LED installations with reduced voltage drop

  • Safety: Short-circuit, overload, no-load and overheating protection. Suitable for furniture installation

  • Comfort: Flicker-free according to IEEE 1789, helping reduce eye strain and improving video recording quality

€33,89 / pc excl. VAT
€40,33 / pc incl. 19% VAT
From Net/pc Gross/pc
1 €33,89 €40,33
5 €33,19 €39,50
10 €32,49 €38,66
20 €31,79 €37,83
◉ In stock
Specifications
Input Voltage
220...240 Vac
Input Current
0,6 A max.
Output Voltage
48 Vdc
Output Current
0,7...2,08 A
Output Power
100 W max.
Dimming method
TRIAC
IP Rating
IP20
Dimensions
Dimension Graph for LED Driver TRIAC Dimmable 48V 100W 2.08A, IP20
