| Menge | Preis |
| 1 - 4 | 9,45€ |
| 5 - 9 | 9,29€ |
| 10 - 19 | 9,19€ |
| 20 + | 9,09€ |
Price on request for order quantity from 50 pieces
Price plus VAT, plus shipping cost
Delivery time: 2-5 workdays inside EU
LS-50V12P (12V 50W)
9,45€
In stock
In stock
Description
LED driver 12V 50W constant voltage for LED strip Lamp flickerfree Furniture installation LED power supply transformator
LS-50V12P
LED power supply for 12 Vdc constant voltage
4.16 A (50 W) max., IP20, independent installation, non-dimmable
Flicker free according to IEEE 1789
Electrical Data
| Input voltage (nominal) | 220…240 Vac |
| Input voltage (range) | 198…264 Vac |
| Mains Frequency | 50/60 Hz |
| Power Factor (λ) | >0.9 |
| Input Current | 0.27 A max. |
| No-load loss | ≤0.5 W |
| Inrush Current | 40 A max. |
| Output Voltage | 12 Vdc |
| Output Current | 0…4.16 A |
| Output Power (nominal) | 50 W max. |
| Efficiency | ≥ 88 % |
| Life Time | > 50,000 h |
| Dimmable | No |
LED driver 12V 50W constant voltage for LED strip Lamp flickerfree Furniture installation LED power supply transformator
Operating Condition
| Operating Ambient Temperature (ta) | -20…+45 °C |
| Max. Surface Temperature (tc) | 90 °C |
| Permitted rel. Humidity | 10…90 % |
| Protection Class | II |
| Type of Protection | IP20 |
Protection
| Short Circuit Protection | Yes * |
| Overload Protection | Yes * |
| Overvoltage protection | Yes * |
| Overheating protection | Yes * |
(*) The output shuts off and will be resumed, after problem is removed and led driver is restarted.
Standards & Certificates
| Standards | EN 61347-1, EN 61347-2-13 EN 61547, EN 55015, EN 62493 EN 61000-3-2, EN 61000-3-3 |
| Approval Marks | CE, UKCA |
| RoHS Compliant | Yes |
LED driver 12V 50W constant voltage for LED strip Lamp flickerfree Furniture installation LED power supply transformator
Installation
| Type of Installation | Independent installation |
| Type of Connection | Screw terminal |
| Cable Cross-section, input side | 0.5…1.5 mm² |
| Cable Cross-section, output side | 0.5…1.5 mm² |
| Cable Preparation length, input side | 6.0 mm |
| Cable Preparation length, output side | 6.0 mm |
Dimension
Connection
LED power supply LS-50V12P: LED transformer constant voltage, input 220 – 240 V (AC), output 12 V (DC), not dimmable, flicker-free, independent installation.
Power: Ideal for LEDs (strips, lamps, GU5,3 / MR16, G4 / MR11) up to 50 W, parallel connection possible. Our products can be used with full load.
Flicker-free: flicker-free light source provides better eye protection and guarantees high-quality video recording.
Assembly: dimensions 101 x 40 x 20 mm (L x W x H), ambient temperature (ta) -20 – +45 °C. Connection by spring loaded clamps, suitable for furniture installation.
Safety: Protection class IP20, protection device overload protection, surge protection, short circuit protection and overtemperature protection.
Quality: CE, furniture approval; Service life > 30.000 hours; Surface temperature (tc) 75°C.
huatec led transformer power supply driver transformator 12v 12 volt dc constant voltage same voltage flicker-free 20w 30w 40w 50w 20 30 40 50 watt led strip lamp gu5.3 mr16 g4 mr11
LED transformer 12V 50W constant voltage
